Specifications for Ropeye Double TDP 18 Deck Bushing
| D (mm) | 10-12 or 12-16 or 16-22 or 22-30 or 30-50 |
| Gewicht (g) | 35 or 37 or 41 or 44 or 52 |
| Material | Anodised Aluminium |
| A (mm) | 48 |
| B (mm) | 14 |
| C (mm) | 24 |
Ropeye Double TDP 18 Deck Bushing – Adjustable & Reinforced Through-Deck Protection
The Ropeye Double TDP 18 Deck Bushing is a high-performance through-deck fitting designed to reinforce the deck while minimising rope friction and chafing. Its dual-component design provides enhanced durability and load distribution at rope entry and exit points. Available in five different sizes to accommodate deck thicknesses ranging from 10mm to 50mm, this bushing is an essential component for Loops, Twinlines, and soft rigging solutions. Specifically designed for use with the Ropeye PRO Loop range, it is also suitable for general through-deck applications.
Key Features:
✔ Prevents Deck & Rope Wear – Reduces friction and abrasion, extending the lifespan of both the deck and rigging.
✔ Adjustable for Different Deck Thicknesses – Available in 10-12mm, 12-16mm, 16-22mm, 22-30mm, and 30-50mm variants.
✔ Durable Anodised Aluminium Construction – Corrosion-resistant and lightweight for long-term performance.
✔ Strengthens the Deck – Distributes load effectively, reducing stress at rope entry/exit points.
✔ Smooth Rope Passage – Ensures a low-friction exit for lines, improving overall rigging efficiency.
Applications:
- Designed for use with the Ropeye PRO Loop range.
- Ideal for protecting deck penetrations where ropes pass through.
- Suitable for Loops, Twinlines, and soft rigging solutions, as well as general through-deck applications.
- Used in both racing yachts and cruising setups where durability and strength are key.
Installation:
- Drill the installation hole to the correct size.
- Clean the area with acetone to ensure a secure and lasting fit.
- Apply adhesive to the bottom section of the Ropeye Double TDP 18 for a secure hold.
- Tighten the bushing in place, ensuring proper alignment for optimal performance.
Warranty: The Ropeye Double TDP 18 comes with a 2-year warranty, ensuring confidence in durability and performance.
Spezifikationen
| D (mm) | 10-12 oder 12-16 oder 16-22 oder 22-30 oder 30-50 |
| Gewicht (g) | 35 oder 37 oder 41 oder 44 oder 52 |
| Material | Anodised Aluminium |
| A (mm) | 48 |
| B (mm) | 14 |
| C (mm) | 24 |
