Specifications for Ropeye Double TDP 14 Deck Bushing
| D (mm) | 10-12 or 12-16 or 16-22 or 22-30 or 30-50 |
| Poids (g) | 20 or 24 or 26 or 28 or 30 |
| Matériau | Anodised Aluminium |
| A (mm) | 40 |
| B (mm) | 12 |
| C (mm) | 20 |
Ropeye Double TDP 14 Deck Bushing – Adjustable & Reinforced Through-Deck Protection
The Ropeye Double TDP 14 Deck Bushing is a high-strength through-deck solution designed to reinforce the deck while reducing rope friction and chafing. Featuring a dual-component design, it provides enhanced durability and load distribution at rope exit points. Available in five different sizes to accommodate deck thicknesses ranging from 10mm to 50mm, this bushing is a key component for Loops, Twinlines, and soft rigging solutions. Specifically designed for use with the Ropeye PRO Loop range, it is also suitable for general through-deck applications.
Key Features:
✔ Prevents Deck & Rope Wear – Reduces friction and abrasion, extending the lifespan of both the deck and rigging.
✔ Adjustable for Different Deck Thicknesses – Available in 10-12mm, 12-16mm, 16-22mm, 22-30mm, and 30-50mm variants.
✔ Durable Anodised Aluminium Construction – Corrosion-resistant and lightweight for long-term performance.
✔ Strengthens the Deck – Distributes load effectively, reducing stress at rope entry/exit points.
✔ Smooth Rope Passage – Ensures a low-friction exit for lines, improving overall rigging efficiency.
Applications:
- Designed for use with the Ropeye PRO Loop range.
- Ideal for protecting deck penetrations where ropes pass through.
- Suitable for Loops, Twinlines, and soft rigging solutions, as well as general through-deck applications.
- Used in both racing yachts and cruising setups where durability and strength are key.
Installation:
- Drill the installation hole to the correct size.
- Clean the area with acetone to ensure a secure and lasting fit.
- Apply adhesive to the bottom section of the Ropeye Double TDP 14 for a secure hold.
- Tighten the bushing in place, ensuring proper alignment for optimal performance.
Warranty: The Ropeye Double TDP 14 comes with a 2-year warranty, ensuring confidence in durability and performance.
Spécifications
| D (mm) | 10-12 ou 12-16 ou 16-22 ou 22-30 ou 30-50 |
| Poids (g) | 20 ou 24 ou 26 ou 28 ou 30 |
| Matériau | Anodised Aluminium |
| A (mm) | 40 |
| B (mm) | 12 |
| C (mm) | 20 |
