Specifications for Harken 20 S/T Radial Bronze Winch
| Recommended line - Max Ø (mm) | 12 |
| Recommended line - Min Ø (mm) | 6 |
| Size | 20 |
| Style | Self-Tailing |
| Material | Bronze |
| Base Ø (mm) | 137 |
| Drum Ø (mm) | 73 |
| Height (mm) | 148 |
| Line entry height (mm) | 61 |
| Gears (Manual) | 1-Speed |
| SWL (kg) | 550 |
| A (mm) | 73 |
| B (mm) | 137 |
| C (mm) | 148 |
| D (mm) | 61 |
| Gear ratio 1 (X : 1) | 2.76 |
| Power ratio 1 (X : 1) | 19.2 |
| Weight (g) | 3900 |
Product specifications
are provided for guidance only, subject to error /
change and without warranty or guarantee. Refer to
manufacturer’s own datasheets / manuals for further
information.
Harken Radial Line winches have successfully balanced the need for a secure grip and line longevity with smooth, controlled easing while under load. Details sailors will appreciate: smaller winches that carry higher loads, stress-free seasonal maintenance, and one-person installation. The self-tailing mechanism on the winch means that one crew member can quickly and easily trim or raise sails. Harken's all-bronze finish enhances your yacht’s classic look, while providing the low-friction pulling power of Harken’s gearing systems.
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
Specifications
| Recommended line - Max Ø (mm) | 12 |
| Recommended line - Min Ø (mm) | 6 |
| Size | 20 |
| Style | Self-Tailing |
| Material | Bronze |
| Base Ø (mm) | 137 |
| Drum Ø (mm) | 73 |
| Height (mm) | 148 |
| Line entry height (mm) | 61 |
| Gears (Manual) | 1-Speed |
| SWL (kg) | 550 |
| A (mm) | 73 |
| B (mm) | 137 |
| C (mm) | 148 |
| D (mm) | 61 |
| Gear ratio 1 (X : 1) | 2.76 |
| Power ratio 1 (X : 1) | 19.2 |
| Weight (g) | 3900 |
