Specifications
| Connection | 0.7m cable |
| Dimensions (mm) | 80 x 52 x 58 |
| Operating temperature | -25°C to 55°C |
| Feed wire gauge Min | 0.5mm2 AWG22 |
| Current draw (mA @ 12VDC) | 520 |
| Current draw (mA @ 24VDC) | 260 |
| Boat size (m) | All Sizes |
| Approved to | IEC 60945 |
| Power supply type | dc. |
| Operating voltage (V) | 10-32 |
| Material | Silver anodized aluminum 25µ, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane |
| Warranty (yrs) | 5 year limited warranty |
| Water resistance | IP68 |
| Weight (g) | 310 |
