Specifications for Ropeye TDP 12 Deck Bushing
| Material | Anodised Aluminium |
| A (mm) | 28 |
| B (mm) | 8 |
| C (mm) | 12 |
| D (mm) | 30 |
| Weight (g) | 8.5 |
Ropeye TDP 12 Deck Bushing – Lightweight & Durable Through-Deck Protection
The Ropeye TDP 12 Deck Bushing is a compact and efficient through-deck fitting designed to protect both the deck and running rigging from excessive wear. Made from anodised aluminium, it strengthens the deck while providing a smooth, low-friction passage for ropes, reducing chafing and prolonging rope life.
Key Features:
✔ Prevents Deck & Rope Wear – Reduces friction and abrasion, helping to extend the lifespan of both the deck and rigging.
✔ Lightweight & Corrosion-Resistant – Constructed from anodised aluminium, offering long-term durability in harsh marine environments.
✔ Deck Reinforcement – Strengthens the deck around the installation point, distributing loads effectively.
✔ Smooth Rope Passage – Provides low-friction guidance for running lines, enhancing efficiency.
✔ Compact & Versatile – Designed for seamless integration into various rigging setups.
Applications:
- Ideal for protecting deck penetrations where ropes enter or exit.
- A key component for installing Loops, Twinlines, and soft rigging solutions.
- Suitable for both racing yachts and cruising setups where weight savings and durability are essential.
Installation:
- Drill the installation hole to the correct size.
- Clean the area with acetone to ensure a solid and secure fit.
- Trim the Ropeye TDP 12 to match the deck thickness – the bushing has a standard length of 30mm and may need to be cut for a precise fit.
- Insert the Ropeye TDP 12 into place, ensuring proper alignment for optimal performance.
Warranty: The Ropeye TDP 12 comes with a 2-year warranty, providing confidence in durability and performance.
Specifications
| Material | Anodised Aluminium |
| A (mm) | 28 |
| B (mm) | 8 |
| C (mm) | 12 |
| D (mm) | 30 |
| Weight (g) | 8.5 |
